Combican-Food

TECHNICAL DATA

MODEL STATION
1		 STATION
2		 STATION
3		 STATION
4		 DIAMETER
(mm)		 HEIGHT
(mm)		   HITS
(x min.)		 THICKNESS
3 STATIONS
 BNA 489 8 Chucks 16 Chucks 8 Chucks 52÷105 40÷200 250÷800 0,10÷0,25
BNA 480 6 Chucks 8 Chucks 6 Chucks 90÷155 90÷260 100÷350 0,13÷0,30
4 STATIONS
 RBNA 504 8 Chucks 8 Chucks 16 Chucks 8 Chucks 52÷105 40÷200 250÷800 0,10÷0,25
RBNA 512 12 Chucks 12 Chucks 16 Chucks 12 Chucks 52÷105 40÷130 400÷1200 0,10÷0,25
  • Low can costs thanks to the possibility of tinplate downgauging.
  • Extremely versating machines with rapid size change-over.
  • Maintenance and adjustment reduced to a minimum.
  • Automatic machine settings for reduced standby speeds during line stop.
  • Machine is controlled by a PLC and operator interfaces via a display panel.
  • Centralized lubrication system with oil recovery system.
  • New Cevolani machines are built with our traditionals standars od durability and solidity. This allows used machinery to keep value in time.
  • Standards components are used. The common Wear and tear spare parts are available in our warehouse.

UPON REQUEST



Customized solutions are available for special cans.
